WEIDMULLER POWER SUPPLY PRO MAX 240W 24V 10A

PRO MAX 240W 24V 10A
1478130000

Version : Power supply, switch-mode power supply unit, 24 V
Order No. : 1478130000
Type : PRO MAX 240W 24V 10A
GTIN (EAN) : 4050118286052
Qty. : 1 pc(s).

AC failure bridging time @ Inom : min. 20 ms
Current limiting : > 120% IN
Degree of efficiency : 91.5%
Derating > 60°C / 75% @ 70°C
Earth leakage current, max. : 3.5 mA
Housing version : Metal, corrosion resistant
Mounting position, installation notice : Horizontal on TS35 mounting rail. 50 mm of clearance at top & bottom for air circ. Can mount side by side with no space in between.
Operating temperature : -25 °C...70 °C
Power factor (approx.) : > 0.95 @ 230 V AC
Power loss, idling : 2.4 W
Power loss, nominal load : 22.3 W
Protection against reverse voltages from the load 30…35 V DC
Protection degree :IP20
Short-circuit protection : Yes
Start-up : ≥ -40 °C
Status indication : LED red/green and relay (≥21.6 V DC LED green, relay on/ ≤20.6 LED red, relay off)
Surge voltage category : III
